FRAME
FACT 11m, X-Wing layout, full carbon chassis and rear end, All-Mountain Geometry, SWAT™ Door integration, threaded BB, fully enclosed internal cable routing, ManFu link, oversized pivot bearings, 12x148mm dropouts, replaceable derailleur hanger, 165mm of travel
FORK
Öhlins RXF 36, 29/27.5+, coil spring, adjustable high and low speed compression, adjustable rebound, 15x110mm thru-axle, 51mm offset, 160mm travel
REAR SHOCK
Custom Öhlins TTX, Twin-Tube design, high and low-speed compression adjust, rebound adjust
INNER TUBES
29x1.75/2.4", 60mm Presta valve
FRONT TYRE
Butcher, GRID casing, 29x2.3", 60TPI, Aramid folding bead, 2Bliss Ready
REAR TYRE
Slaughter, GRID casing, 29x2.3", 60TPI, Aramid folding bead, 2Bliss Ready
CRANKSET
RaceFace Aeffect, 6000-series alloy, 24mm spindle, 52mm chainline, 28T
BOTTOM BRACKET
SRAM GXP XR, 73mm
SHIFT LEVERS
SRAM GX, 11-speed, trigger
REAR DERAILLEUR
SRAM GX, long cage, 11-speed
CASSETTE
SRAM XG-1150, 11-speed, 10-42t
CHAIN
SRAM PC-1110, 11-speed w/PowerLink
FRONT BRAKE
SRAM Guide R, hydraulic disc, organic pads, Guide S4 4-piston caliper, 200mm rotor
REAR BRAKE
SRAM Guide R, hydraulic disc, organic pads, Guide S4 4-piston caliper, 180mm rotor
HANDLEBARS
Specialized DH, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 780mm, 31.8mm
GRIPS
Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
STEM
Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Command Post IRcc, 12 position micro-height adjustable, alien head design, bottom mount cable routing, remote adjust SRL lever, 30.9mm, S: 100mm, M/L/XL: 125mm travel
SEAT BINDER
Specialized, alloy, 2-bolt, 27.2mm
PEDALS
Resin Test Ride w/toe clips
