Specification |
Features |
|
Capable and stiff 130 mm frame is 29˝ and 27.5+ compatible |
|
Boost148/110: stronger wheels, more tyre clearance, shorter stays |
|
Exclusive suspension tech with ABP, Full Floater and RE:aktiv |
|
Straight Shot stiffness, Knock Block frame defence |
Frameset |
Frame |
OCLV Mountain Carbon main frame and seatstay, alloy chainstay, ABP, Boost148, Knock Block steerer stop, Full Floater, EVO link, E2 tapered head tube, Mino Link, Control Freak internal routing, Carbon Armour, PF92, ISCG 05, G2 Geometry, 130 mm travel |
Front suspension |
Fox Performance 34 Float, GRIP 3-position damper, E2 tapered steerer, G2 Geometry w/51 mm offset, Boost110, 130 mm travel |
Rear suspension |
Fox Performance Float EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 210x52.5 mm |
Wheels |
Wheels |
Bontrager Line Elite 30, Tubeless Ready, 108T Rapid Drive, Boost110 front, Boost148 rear (tubeless strips included, valves sold separately) |
Tires |
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength side walls, 120tpi, aramid bead, 29x2.40" |
Drivetrain |
Shifters |
Shimano Deore XT M8000, 11-speed |
Front derailleur |
Shimano Deore XT M8020 |
Rear derailleur |
Shimano Deore XT M8000, Shadow Plus |
Crank |
Shimano Deore XT, 36/26 |
Bottom bracket |
PF92 |
Cassette |
Shimano Deore XT, 11-42, 11-speed |
Chain |
Shimano HG70 |
Pedals |
Not included |
Components |
Saddle |
Bontrager Evoke 3, titanium rails |
Seatpost |
Bontrager Drop Line, internal routing, 31.6 mm (15.5: 100 mm/17.5 & 18.5: 125 mm/19.5 & 21.5: 150 mm) |
Handlebar |
Bontrager Line Pro, OCLV Carbon, 35 mm, 15 mm rise, 750 mm width |
Stem |
Bontrager Line Pro, Knock Block, 35 mm clamp, 0 degree, 60 mm length |
Grips |
Bontrager Race Lite, lock-on |
Headset |
Knock Block Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
Brakeset |
Shimano Deore XT M8000 hydraulic disc |
|
Upgrades from Fuel EX 9.7 29 |
|
OCLV Mountain Carbon seatstay |
|
Fox Performance 34 Float fork |
|
Bontrager Line Elite 30 wheels |
|
Shimano Deore XT M8000 2x11 drivetrain |
|
Shimano Deore XT M8000 brakes |
