ENGINE
Bosch, Performance CX Smart System, 250 W, 85 Nm
DISPLAY
Bosch, Kiox 300 + LED Remote
BATTERY
Bosch, PowerTube, 750 Wh
FRAME FAMILY
Haibike, AllMtn Bosch CF Smart System, Carbon/aluminium
FORK
RockShox, Lyrik Select RC, Air/oil, 160 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
DAMPER
RockShox, Deluxe Select Plus, Air, Trunnion Mount
CRANK ARM
Haibike Components, The Crank ++, Aluminium
BRAKE (FRONT)
Magura, MT5, 4-piston disc brake
BRAKE (REAR)
Magura, MT5, 4-piston disc brake
TUBE
Presta valve
CLAMPING RING
Internal hexagon, 34.9 mm
REAR DERAILLEUR
Shimano, Deore XT M8100 Shadow Plus
SHIFT LEVER
Shimano, Deore SLX M7100
BOTTOM BRACKET
integrated in the motor
SPROCKET
Shimano, M6100, 10 - 51 teeth
CHAIN
Shimano, CN-M6100
CHAINRING
Aluminium, 36 teeth
CHAIN GUIDE
Nylon directmount
BRAKE LEVER
Magura, MT5 HC-lever
BRAKE DISC (FRONT)
Magura, MDR-C 203, 203 mm
BRAKE DISC (REAR)
Magura, MDR-C 203, 203 mm
TYRE
Maxxis, Minion DHF II, 65-622, 29 x 2.5 inch
WHEEL SET
DT Swiss, H1900
HANDLEBAR
Haibike Components, TheBar ++, 780 mm
GRIPS
Haibike, MTB grips
STEM
Alu, A-head, 31.8 mm
HEADSET
Acros, Cable integration, Aluminium
SADDLE
fi'zi:k, Terra Aidon X5-160
SEAT POST
Dropper-Post Remote 31.6, Aluminium, Telescope, 31.6 mm
PEDALS
Freeridepedal, Aluminium, with Reflector
PERMITTED TOTAL WEIGHT
120.0 kg
TYRE (REAR)
Maxxis, Minion DHR II, 71-584, 27.5 x 2.8 inch
