ENGINE
Yamaha, PW-X3, 250 W, 85 Nm
DISPLAY
Yamaha, Side Switch, 1.7" LCD, 7 functions
BATTERY
InTube, 750 Wh
FRAME FAMILY
Haibike, AllMtn PW-X3, Aluminium
FORK
RockShox, Yari RC, Air, 160 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
DAMPER
RockShox, Deluxe Select Plus, Air, Trunnion Mount
CRANK ARM
Haibike Components, The Crank ++, Aluminium
BRAKE (FRONT)
Shimano, M6120, Hydraulic disc brakes
BRAKE (REAR)
Shimano, M6120, Hydraulic disc brakes
TUBE
Presta valve
RIM
WTB, ST i30 TCS, Double Wall
CLAMPING RING
Internal hexagon, 38.1 mm
REAR DERAILLEUR
Shimano, SLX M7100
SHIFT LEVER
Shimano, Deore SLX M7100
BOTTOM BRACKET
integrated in the motor
SPROCKET
Shimano, M6100, 10 - 51 teeth
CHAIN
Shimano, CN-M6100
CHAINRING
Haibike Components, Aluminium, 36 teeth
CHAIN GUIDE
Nylon directmount
BRAKE LEVER
Shimano, Deore M6100, Aluminium
BRAKE DISC (FRONT)
Shimano, RT30-L, 203 mm
BRAKE DISC (REAR)
Shimano, RT EM300L, 203 mm
TYRE
Maxxis, Minion DHF II, 63-622, 29 x 2.5 inch
FRONT WHEEL HUB
Shimano, MT410-B, Centerlock
REAR WHEEL HUB
Shimano, MT410, Centerlock
SPOKES
Sapim, Race
HANDLEBAR
Haibike Components, TheBar +++, 780 mm
GRIPS
Haibike, MTB grips
STEM
Haibike Components, TheStem +++, 31.8 mm
HEADSET
Acros, BlockLock, Aluminium
SADDLE
Selle Royal, Vivo
SEAT POST
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
PEDALS
Freeridepedal, Aluminium, with Reflector
PERMITTED TOTAL WEIGHT
150.0 kg
TYRE (REAR)
Maxxis, Minion DHR II, 66-584, 27.5 x 2.6 inch
RIM (REAR)
WTB, ST i35 TCS, Double Wall
