Frame:
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Fork:
Fox 36 Float AWL, RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 150mm
Shock:
Fox Float Rhythm R, 230x60mm (27.5: 210x55mm), Rebound Adjust
Shock hardware:
Front: 30x8mm, Rear: DU-Bushing 12,7mm
Headset:
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment
Stem:
CUBE Performance Stem E-MTB 35, FPI-Link
Handlebar:
CUBE Rise Trail Bar 35
Grips:
ACID Disrupt
Rear derailleur:
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Chain guide:
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Shifters:
Shimano Deore SL-M6100, Rapidfire-Plus
Brake:
Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
Crankset:
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
Crankset chainring sizes:
34T
Cassette:
Shimano Deore CS-M6100, 10-51T
Number of gears:
12
Chain:
KMC e12
Rims:
CUBE EX30, 32H, Disc, Tubeless Ready
Front hub:
CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt
Rear hub:
CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt
Front tire:
Schwalbe Hans Dampf, Addix Soft, Super Trail, Tubeless Easy, 2.6
Rear tire:
Schwalbe Hans Dampf, Addix Speedgrip, Super Trail, Tubeless Easy, 2.6
Saddle:
ACID Venec EMTB Trail 140
Seatpost:
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Seat post = dropper Yes/No:
YES
Seatpost clamp:
CUBE Semi-Integrated
Engine:
Bosch Drive Unit Performance Line CX, Smart System
Battery:
Bosch PowerTube
Charger:
Bosch 2A
Remote:
Bosch System Control incl. Mini Remote
